DAC Audio Research DAC 8

Balanced XLR 6.6V RMS (16.4dBV) max.
Single-Ended RCA 3.3V RMS (10.4dBV) max.
OUTPUT IMPEDANCE
500 Ω Bal, 250 Ω SE
FREQUENCY RESPONSE
0.5Hz – 90kHz, +0 -3dB
20Hz – 20kHz, +0 -.15dB
SIGNAL TO NOISE RATIO
>114dB
TOTAL HARMONIC DISTORTION
0.015%
IMD + NOISE
0.013%
QUAD DAC RESOLUTION
24 bits each
CHANNEL SEPARATION
105dB
INPUTS, DIGITAL, ALL GALVANICALLY ISOLATED
USB 2.0 HS (480Mbps) 44.1 to 192kHz
RCA 75Ω SPDIF, 44.1 to 192kHz
BNC 75Ω SPDIF, 44.1 to 192kHz
XLR 110Ω SPDIF, AES/EBU 44.1 to 192kHz
OPT 660nM Toslink Fiber 44.1 to 96kHz
MASTER OSCILLATOR
22.579mHz ±20Hz, for 44.1, 88.2 & 176.4kHz
24.576mHz±20Hz, for 48, 96 & 192kHz
INTRINISIC JITTER
<10pS
POWER SUPPLY
2 Transformers, 7 Regulators
POWER REQ. (detachable power cord)
100-125VAC 60Hz (200-250VAC 50/60Hz)
18W max, Sleep Mode 4W
COMPLIANCE
FCC & CE
FRON PANEL DISPLAY
POWER ON, MUTE, INVERT, INPUT SELECT, SAMPLE RATE BEING PLAYED
FRONT PANEL CONTROL FUNCTIONS
POWER: on/off, INVERT: output polarity, INPUT: select (advance), MUTE: outputs
INFRARED REMOTE CONTROL FUNCTIONS
POWER: on/off, MUTE: outputs, INPUT: USB, RCA, BNC, XLR, OPT, USB: play/pause, previous, next, stop. INVERT: output polarity
DIMENSIONS
19” (48cm) W x 5.25” (13.4cm) H x 10” (25.4cm) D. Handles extend 1.5” (3.8cm) forward of the front panel. Rear connectors extend .75” (1.9cm)
WEIGHT
11.5lbs. (5.2kg) Net; 18lbs. (8.2kg) Shipping
