Lector CDs Moon 260D

The MOON 260D Player is the perfect companion source component for the 250i Integrated Amplifier. Incorporating technologies found in our highly acclaimed MOON CD players, the MOON 260D uses highly advanced digital and analog circuitry to produce an astounding level of sonic performance with no equal in its price range.

With features including a fully customized CD transport mechanism, a bidirectional RS-232 port, a large easy-to-read display, an IR input for external control, and luxurious industrial build quality, the 260D will provide for many years of listening pleasure and hassle-free use.


--------------------------------------------------------------------------------


Significant Design Features:

· 8 stages of DC voltage regulation
· Internal upsampling which uses 24-bit/352.8kHz processing
· Proprietary CD drive system with in-house developed hardware & software
· BurrBrown PCM1793 high-resolution 24-bit/192-kHz Digital-to-Analog Converter and
8X oversampling digital filter
· RS-232 port for i) full unsolicited bidirectional feedback in custom installation setups
and ii) firmware updates
· IR input for external control
· SimLink controller port allows for 2-way communications between other compatible
MOON components
· All digital and analog audio circuitry mounted on a single circuit board, each with their
own respective ground plane, to minimize signal path lengths and eliminate any
potential for interference and signal degradation
· Accurate digital clocking system for exceptionally low intrinsic jitter levels
· Advanced analog signal path using a DC servo circuit and proprietary analog filter
· PCB w/ pure copper tracings & gold plating that yields low impedance characteristics
· Optimized selection of very high quality electronic components
· Designed to be powered up at all times for optimal performance.

 Configuration Single-ended
Transport Mechanism Proprietary Design

Front Panel
Controls
Stand by · Play · Pause · Stop · Previous Track · Next Track· Open / Close
Front Panel
Display
Track number · Time (elapsed or remaining for track or disc)
Front Panel
LED Indicators
Programming · Scan · Random · Repeat (disc and track)

DAC / Digital Filter BurrBrown PCM1793
Frequency Response (audible) 20Hz - 20kHz +0/-0.2dB
Frequency Response (full range) 2Hz - 72kHz +0/-3dB
THD @ 1kHz, 0dBFS (A-weighted) < 0.002 %
IMD < 0.005 %
Dynamic Range > 110dB
Signal-to-noise ratio > 110dB @ full output
Channel Separation > 106dB
Low Level Linearity ±1.0dB to below 120dBFS
Intrinsic Jitter < 300 picoseconds RMS
Single-ended Analog Outputs 1 pair RCA
Digital Output S/PDIF (RCA)
Max. Analog Output @ 0dBFS - RCA 2.0 Volts @ 100 Ω
Digital Output Impedance S/PDIF 75 Ω @ 0.5 Volts

SimLink Port 1 input + 1 output each on 1/8" mini-jack
RS-232 Port 9-pin female DB connector
IR input 1/8" mini-jack

Available Faceplate Finishes Black and Silver
Remote Control Full Function
Power Consumption @ idle 15 Watts
AC Power Requirements 120V / 60Hz 240V / 50Hz
Fuse Replacement - 120V 0.2A short slow blow
Fuse Replacement - 230V 0.1A short slow blow
Shipping weight 14 lbs / 6.25 kgs
Dimensions (W x H x D) 16.88 x 3.5 x 13.07 in. (42.9 x 8.9 x 33.2 cm.)
