Electrocompaniet ECI-5
  • Electrocompaniet ECI-5
  • Electrocompaniet ECI-5
  • Electrocompaniet ECI-5
  • Electrocompaniet ECI-5

Electrocompaniet ECI-5

Electrocompaniet ECI-5
Novedad

descatalogado y agotado. No disponible

Producto con envío gratuito

  • Pregunta al especialista

    • Rendimiento en clase A, construcción dual mono, 2 x 120W a 8 ohmios y 2 x 200W a 4 ohmios, respuesta en frecuencia de 1Hz a 150KH, circuitería completamente balanceada, entrega de corriente hasta 80 amp, 3 entradas RCA estéreo y 2 entradas XLR estéreo, 1 salida RCA de grabación, 1 salida RCA y otra XLR de previo, mando a distancia, medidas 483 x 135 x 405mms, amplificador integrado de 2 x 120 Watios. Entradas RCA y XLR.  Producto Ex Demo, 2 años de garantía.



    The Electrocompaniet ECI 5 is a DC coupled high performing, fully balanced, remote controlled integrated stereo amplifier with all latest upgrades included. Six inputs: two balanced three single and one direct. Outputs: Balanced, single and REC. Balanced motorized volume control that does not degrade the sonic qualities of the unit. Relay input switching. Volume and input sources can easily be navigated via four Navigator touch buttons on the front panel or from the remote control. The select source is shown in the Navigator window. The ECI 5 Features Electrocompaniet's unique FTT (Floating Transformer Technology) power supply designs. The ECI 5 contains the same components used in our most prestigious models. A current reservoir of 70.000uF delivers 2 x 120W of clean and powerful dynamics into an 8 ohms load. Like the rest of our amplifiers, ECI 5 is stable down to 0.5 ohms. The balanced output of the ECI 5 can feed an additional power amplifier in a bi-amped set-up. Technical specifications -------------------------------------------------------------------------------- All measurements are made at 120V / 240V //50Hz / 60Hz Preamplifier section Nominal Input impedance 330Kohm Max. input level > 10 Volt RMS Equivalent input noise < 4 µV Pre-out gain balanced output (XLR) 1,37x Pre-out gain single output (RCA) 1,25x Amplifier section Output Impedance (20 Hz -20 kHz) < 0,01 Ohm Max. peak current > 80 A THD (measured at 1 kHz half power, 8 W) < 0,007 % THD (measured at 1 kHz -1 dB 8 W) < 0,008 % Input sensitivity for rated output single ended 1,4V Input sensitivity for rated output balanced 0,7V Input sensitivity for rated output HT 6,5V Rated output power 8 W 2 x 120 W 4 W 2 x 200 W 2 W 2 x 350 W Power consumption (no load or signal) 160 W



    Medidas Ancho 483 x Alto 135 x Fondo 405 mm y peso de 16 Kgs 2350

    Electrocompaniet ECI-5
