Classe CA-5200
  • Classe CA-5200

Classe CA-5200

Classe CA-5200
Novedad

producto descatalogado y agotado

Pregunta al especialista
Envío gratuito
The CA-5200 is a 5 x 200W model, based on the same channels used in the CA-2200. Power supply components are large enough to allow for the greater power demands of five channels without sacrificing performance. Design features include balanced circuitry, overbuilt power supplies and oversized output stages to ensure the highest performance at every output level, with any loudspeaker. models (balanced inputs) CA-5200 voltage gain 29.1dB bandwidth 155kHz (-3dB) 22kHz (-0.1dB) phase < -10° (22kHz) sensitivity 1.4Vrms power/channel (continuous) (120VAC line, 1kHz signal regulated to 1% THD + noise into resistive load, all channels driven) load (resistive) 8Å® 200W 4Å® 370W THD + noise (unweighted, 10Hz - 500kHz bandwidth, 1Vrms/1kHz input) load (resistive) none 0.002% 8Å® 0.003% 4Å® 0.005% noise FFT noise floor peaks all below -95dBV (with terminated inputs) S/N ratio (relative to 1kHz sine wave full level output into 8Å®) 108dB height depth (excluding connectors) width gross weight net weight 8.75" (222 mm) 21.0" (533 mm) 17.5" (445 mm) 133 lbs (60 kg) 121 lbs (55 kg) rated power consumption 1056W
