Etapa Audio Research DS 225

3997
Novedad

producto agotado y descatalogado. No disponible

Producto con envío gratuito

  • Rendimiento en clase D, circuitería totalmente balanceada, 2 x 225W a 8 ohmios, respuesta en frecuencia de 5Hz a 45KHz, entrada de audio RCA y XLR balanceados, toma trigger de 12V. Etapa de potencia estereo, 2x225w. Amplificación digital.



    AUDIO RESEARCH DS 225
    DS 225 Specifications: POWER OUTPUT: 225 watts per channel into 8 ohms from 20Hz to 20kHz.

    FREQUENCY RESPONSE: (-3dB points at 1 watt) 0.4Hz to 300 kHz.

    INPUT SENSITIVITY: 3.2V RMS BAL for rated output. (20 dB Bal gain into 8 ohms.)

    INPUT IMPEDANCE: 300K ohms Balanced, 150k ohms SE.

    OUTPUT POLARITY:
    Non-inverting. Balanced input pin 2+ (IEC-268).

    OUTPUT REGULATION: Approximately 0.05dB 8 ohm load to open circuit (Damping factor approximately 170).

    OUTPUT CURRENT: 60 Amps Peak (1 millisecond)

    HUM & NOISE: Less than 0.05mV RMS -116dB below rated output (IHF weighted, input shorted).

    POWER REQUIREMENTS: 105-125VAC 60Hz (210-250VAC 50 Hz) 500 watts at rated output (130 WPC 8 ohms) 600 watts max, 150 watts idle.

    DIMENSIONS: 19" (48.3 cm) W x 6.25" (15.9 cm) H x 15" (38.1 cm) D. Handles extend 1.5" (3.8 cm) forward.

    WEIGHT: 42.8 lbs. (19.5 kg) Net; 55.3 lbs. (25.2 kg) Shipping.


    Specifications subject to change without notice.
