Classe CA-3200

Classe CA-3200
Novedad

producto descatalogado y agotado

Producto con envío gratuito

  • The CA-3200 is a 3 x 200W model, based on the same channels used in the CA-2200. Power supply components are larger in this model to allow for greater power demands without sacrificing performance. Design features include balanced circuitry, overbuilt power supplies and oversized output stages to ensure the highest performance at every output level, with any loudspeaker. models (balanced inputs) CA-3200 voltage gain 29.1dB bandwidth 155kHz (-3dB) 22kHz (-0.1dB) phase < -10° (22kHz) sensitivity 1.4Vrms power/channel (continuous) (120VAC line, 1kHz signal regulated to 1% THD + noise into resistive load, all channels driven) load (resistive) 8Å® 200W 4Å® 390W THD + noise (unweighted, 10Hz - 500kHz bandwidth, 1Vrms/1kHz input) load (resistive) none 0.002% 8Å® 0.003% 4Å® 0.005% noise FFT noise . oor peaks all below -95dBV (with terminated inputs) S/N ratio (relative to 1kHz sine wave full level output into 8Å®) 108dB height depth (excluding connectors) width gross weight net weight 8.75" (222 mm) 18.5" (470 mm) 17.5" (445 mm) 102 lbs (46 kg) 90 lbs (41 kg) rated power consumption 672W
    Classe CA-3200
